FILTRATION AND ATEX FILTERS

At Siapro, we manufacture all key components for industrial filtration systems, including ATEX solutions for explosive atmospheres. All production is carried out in modern, fully equipped manufacturing centers, ensuring complete quality control and fast delivery.

Our production includes:

• dust extraction units from small capacities to large centralized stations
• pre-separators, cyclones and silos
• collecting devices: hoppers, rotary valves, double flap valves
• screw conveyors and chain conveyors
• electrical control cabinets with monitoring systems

Siapro filtration systems are designed for reliable operation, long service life and high dust removal efficiency across various industries (metal processing, foundries, woodworking, energy, shotblasting, grinding, etc.).

Siapro filtration units are divided into four main groups, ranging from compact units to large industrial dust extraction systems:

1. Cartridge filters (details below)

Most commonly used for plasma cutting, shotblasting, welding and workplace dust extraction.

2. Bag filters

Larger industrial filters for foundries, woodworking and applications with high dust loads.

3. Pocket filters

Large dust extraction units with capacities up to 80,000 m³/h, suitable for demanding and continuous processes.

4. Wet filters

For applications where dry filtration is difficult to implement or where additional safety is required.

Cartridge filters are ideal for dust extraction and filtration across many industries. They are designed to provide high efficiency, low emissions, quiet operation and easy maintenance.

How do they work?

Contaminated air enters the filter through a pre-chamber where larger particles are separated. The air then passes through the cartridges, which retain the dust. The cartridges are cleaned with compressed air, ensuring long-term and stable operation.

Where are they used?

• shotblasting machines
• plasma cutters
• welding equipment
• industrial grinding
• silos
• metal and cement processing
• dust control in production areas

Main advantages of cartridge filters:

• very low emissions and high filtration efficiency
• quiet operation (68–75 dBA, depending on model)
• modular design (1–48 cartridges)
• capacity from 500 to 48,000 m³/h
• compact design – installation close to the pollution source
• easy maintenance and accessible service doors
• various cartridge materials: cellulose, polyester, PTFE, antistatic

Siapro also provides service, technical support and spare parts supply.
